Trane RAUJ-C60 - Page 11

SS-SVX11K-EN
11
Figure 2. Component layout and ‘ship-with’ locations – 20 to 60 ton units
1
Condenser
Coil
Access
Panels
Lifting
Bracket
(2/side)
Condenser
Air Intake
Grills
“Ship-
with”
Area
Control
Panel
Compressors
Condenser
Fans
Figure 3. Component layout and ‘ship-with’ locations – 80 to 120 ton units
2
Condenser
Coil
Access
Panels
Lifting
Bracket
(2/side)
Condenser
Air Intake
Grills
Control
Panel
Compressors
Condenser
Fans
“Ship-
with”
Area
GGeenneerraall IInnffoorrmmaattiioonn
1.
60 ton unit shown
2.
120 ton unit shown
