Table 3. Unit clearances
Clearance (in)
Dimension Location 20 to 60 tons 80 to 120 tons
A Front 72 96
B Back 72 96
C
Left (control panel side)
42 48
D Back 42 48
E
Distance between units (side-by-side)
192 192
F Pit installation - front and back 192 192
G Pit installation - sides 48 48
DDiimmeennssiioonnss aanndd WWeeiigghhttss
