Trane RAUJ-C60

SS-SVX11K-EN
27
Figure 16. Air-cooled condensing unit connections — 80 ton
1 1/8" O.D.
LIQUID LINE
2 1/8" O.D .SUCTION LINE
COIL
2 1/8" O.D. SUCTION LINE
1 3/8" O.D. HOT GAS
BYPASS (OPTIONAL)
COMPRESSOR (6)
1 3/8" HOT GAS
BYPASS (OPTIONAL)
COMPRESSOR (6)
HOT GAS BYPASS
(OPTIONAL)
14 13/16"
25 1/8"
46 3/16"
SERVICE VALUE
(OPTIONAL SEE DETAIL A)
42 9/16"
25 1/8"
14 1/16"
19 1/16"
73 3/8"
45 9/16"
CONTROL
PANEL SIDE
18 5/16"
SUCTION LINE
LIQUID LINE
DETAIL A
VOLTAGE
ACCESS
CONTROL
PANEL
CONTROL
PANEL SIDE
5 9/16"
9 3/8"
LIQUID LINE
COIL
COMPRESSOR (6)
SERVICE VALUE
(OPTIONAL SEE DETAIL A)
DIMENSIONAL CONNECTION DRAWING
80 TON UNIT
DETAIL A
DETAIL DRAWING
NOTES:
1
. VERIFY WEIGHT, CONNECTION, AND ALL DIMENSION WITH
INSTALLER DOCUMENTS BEFORE INSTALLATION
PLAN VIEW OF UNIT
CONNECTION DRAWING
CONNECTION DRAWING
CONTROL PANEL SIDE VIEW OF UNIT
LEFT VIEW OF UNIT
CONNECTION DRAWING
ISOMETRIC DRAWING
ORIENTATION VIEW OF UNIT
DDiimmeennssiioonnss aanndd WWeeiigghhttss
