2
General Data (380-415V)(50Hz)
Air Cooled Outdoor Unit
UNIT MODELS
RAUP250D
RAUP300D
RAUP400D
RAUP500D
RAUP600D
POWER CONNECTION
V/ph/Hz
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
MCA
1
A 53.9 58.1 91.6 102.1 110.1
PERFORMANCES
2
Gross Cooling Capacity
2
kW (MBH) 73.9 (253) 90.3 (308) 113.9 (389) 147.9 (505) 180.5 (617)
Unit Capacity Steps (%)
100-50
100-50
100-75-50-25
100-75-50-25
100-75-50-25
Total Compressor Power Input
2
kW 25.2 26.8 36.2 50.4 53.6
Sound Power Level
dB (A)
87
89
89
90
92
SYSTEM DATA
Refrigerant Type
R22 / R407C
R22 / R407C
R22 / R407C
R22 / R407C
R22 / R407C
No. Refrigerant Circuits
1
1
2
2
2
Refrigerant Connection Type
Sweat
Sweat
Sweat
Sweat
Sweat
Refrigerant Charge approximate per circuit
lb (kg)
44 (20)
60.6 (27.5)
43 (19.5)
44 (20)
60.6 (27.5)
Suction Line OD
in (mm)
2-1/8
2-1/8
1-5/8
2-1/8
2-1/8
Liquid line OD
in (mm)
7/8
7/8
7/8
7/8
7/8
COMPRESSOR
Compressor Type
Scroll
Scroll
Scroll
Scroll
Scroll
No. Used
2
2
4
4
4
Model
13T+13T
15T+15T
2x(10T+10T)
2x(13T+13T)
2x(15T+15T)
Speed Number
1
1
1
1
1
Motor Number
1
1
1
1
1
V/ph/Hz
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
380-415/3/50
RLA/LRA (each)
2
A 22.9/145 24.2/175 20.7/130 22.9/145 24.2/175
Motor RPM
rpm
2900
2900
2900
2900
2900
COIL
Coil Size (HxL)
in
63x71
63x80
46x71
58x71
50x96
mm
1,600x1,803
1,600x2,032
1,168x1,803
1,473x1,803
1,270x2,444
No. Used
1
1
2
2
2
Face Area
sq ft (m
2
)
31.06 (2.88) 35.00 (3.25) 45.36 (4.21) 57.19 (5.31) 66.66 (6.21)
8/3)5.9( 8/3)5.9( 8/3)5.9( 8/3)mm( ni DO eziS ebuT (9.5) 3/8 (9.5)
Tube Type Plain Plain Plain Plain Plain
Rows 33333
Fin Type
Fins per inch 12 12 12 12 12
Refrigerant Flow Control -----
FAN
Fan Type
Propeller
Propeller
Propeller
Propeller
Propeller
No. used
2
3
3
4
6
)82(017 )82(017 )82(017 )82(017 )82()mm( niretemaiD 710
No. of Blade 44444
9292929292eergedelgnA hctiP
Drive Type Direct Direct Direct Direct Direct
Nominal Airflow
3
cfm (cmh)
11,500 (19,539)
15,000 (25,485)
17,100 (29,053)
22,280 (37,853)
29,400 (49,950)
MOTOR
No. of Motor 23346
.0)3.0( 4.0)3.0( 4.0)3.0( 4.0)Wk( ph)hcae( ph rotoM 4 (0.3) 0.4 (0.3)
No. of Speed 11111
578578578578578mprdeepS rotoM
V/ph/Hz 380-415/3/50 380-415/3/50 380-415/3/50 380-415/3/50 380-415/3/50
RLA/LRA (each) 1.2/3.40 1.2/3.40 1.2/3.40 1.2/3.40 1.2/3.40
DIMENSION (HxWxD)
x7758x311x5665x621x7665x301x76 ni )gnippihS( detarC 113x85 73x128x85
mm
1,700x2,620x1,420
1,700x3,200x1,420
1,650x2,880x2,160
1,960x2,880x2,160
1,850x3,240x2,160
7x201x8667x201x6584x611x8584x09x85 ni)teN( detarcnU 6 60x117x76
mm
1,465x2,294x1,222
1,465x2,952x1,222
1,414x2,583x1,920
1,718x2,583x1,920
1,515x2,980x1,920
WEIGHT
2)067( 5.576,1)446( 8.914,1)gk( bl)gnippihS( detarC ,284 (1,036) 2,824 (1,281) 2,745 (1,245)
02,2)047( 4.136,1)426( 7.573,1)gk( bl)teN( detarcnU 7 (1,001) 2,747 (1,246) 2,668 (1,210)
Minimum Outdoor Air Temperature for Mechanical cooling
Standard Ambient Operating Range
F
59-133
59-133
59-133
59-133
59-133
C 15-45 15-45 15-45 15-45 15-45
High Pressure (cut out / cut in)
psig
Low Pressure (cut out / cut in)
psig
1
MCA - Minimum Circuit Ampacity is 125% of the largest compressor RLA plus 100% of the other compressor RLA plus the sum of the motor RLA.
2
At 7 deg C SST and 35 deg C Ambient, 400V, Subcooling 8.3 K, Superheat 11.1 K.
3
Nominal Airflow is rated with standard air-dry coil.
Uncoat Corrugated Fin
398 14 / 313 21
27 7 / 45.5 7
± ±
± ±
