15
RTAA-IOM-3
Figure 5
Typical RTAA Unit
(with Remote Evaporator Option)
(Rear Exterior View)
Condenser
Fans/Motors
Circuit #1
Condenser
Fans/Motors
Circuit #2
Condenser
Circuit #1
Condenser
Circuit #2
Circuit #1
Field Refrigerant
Piping Connections
Circuit #2
Field Refrigerant
Piping Connections
