18
RTAA-IOM-3
Figure 6
Remote Evaporator
Refrigerant
Suction Line
Circuit #1
Refrigerant
Suction Line
Circuit #2
Entering Chilled
Water Temp. Sensors
Leaving Chilled Water
Temperature Sensor
Evaporator
Refrigerant
Temperature
Sensors
Electronic
Expansion
Valve
Sight
Glass
Filter/Dryer
Terminal Box
Refrigerant
Liquid Line
Circuit #1
