Trane RTAC 225 Series User Manual

22 RTAC-SVX002A-EN
Installation Mechanical
Tab. III - 01 – Aluminum n unit weights (60 Hz units)
Unit Size
W1 W2 W3 W4 W5 W6 W7 W8 Operating
Weight
Shipping Weight Xcg Ycg
lb lb lb lb lb lb lb lb lb lb in in
kg kg kg kg kg kg kg kg kg kg mm mm
RTAC 140 STD
2423 2794 2602 2933 NA NA NA NA 10995 10752 88 45
1099 1267 1180 1330 4987 4877 2235 1143
RTAC 140 HIGH
2426 2800 2610 2943 NA NA NA NA 11057 10780 88 45
1100 1270 1184 1335 5015 4885 2235 1143
RTAC 155 STD
2427 2796 2608 2937 NA NA NA NA 11034 10769 88 45
1101 1268 1183 1332 5005 5460 2235 1143
RTAC 155 HIGH
3095 3489 2530 2924 NA NA NA NA 12332 12038 106 45
1404 1583 1148 1327 5594 4897 2692 1143
RTAC 170 STD
2429 2803 2615 2948 NA NA NA NA 11073 10796 88 45
1102 1272 1186 1337 5023 5488 2235 1143
RTAC 170 HIGH
3106 3506 2543 2944 NA NA NA NA 12418 12098 106 46
1409 1590 1153 1335 5633 5621 2692 1168
RTAC 185 STD
3222 3562 2634 2973 NA NA NA NA 12685 12391 106 44
1462 1616 1195 1349 5754 6304 2692 1118
RTAC 185 HIGH
4037 4117 2990 3581 NA NA NA NA 14214 13897 124 45
1831 1867 1356 1624 6447 5799 3150 1143
RTAC 200 STD
3260 3756 2796 3212 NA NA NA NA 13104 12784 106 45
1479 1704 1268 1457 5944 6462 2692 1143
RTAC 200 HIGH
3632 4187 3110 3578 NA NA NA NA 14593 14247 124 45
1648 1899 1411 1623 6619 6518 3150 1143
RTAC 225 STD
3632 4229 3114 3632 NA NA NA NA 14687 14370 124 45
1647 1918 1413 1647 6662 7184 3150 1143
RTAC 225 HIGH
2569 2892 2477 2800 2388 2711 NA NA 16184 15838 166 44
1165 1312 1124 1270 1083 1230 7341 6580 4216 1118
RTAC 250 STD
3691 4165 3088 3562 NA NA NA NA 14853 14507 124 45
1674 1889 1401 1616 6737 7243 3150 1143
RTAC 250 HIGH
2601 2897 2512 2808 2427 2723 NA NA 16314 15968 166 44
1180 1314 1140 1274 1101 1235 7400 8562 4216 1118
RTAC 275 STD
3345 2936 3351 2942 3356 2947 NA NA 19536 18876 176 42
1517 1332 1520 1334 1522 1337 8862 9193 4470 1067
RTAC 275 HIGH
3251 2863 3571 3183 3894 3505 NA NA 20944 20266 203 42
1475 1299 1620 1444 1766 1590 9500 9319 5156 1067
RTAC 300 STD
3456 3074 3615 3233 3774 3393 NA NA 21103 20544 222 42
1568 1394 1640 1466 1712
1539 9572 10210 5639 1067
RTAC 300 HIGH
2955 2628 2892 2565 2782 2495 2759 2432 22060 22508 222 42
1340 1192 1312 1163 1262 1132 1251 1103 10006 9730 5639 1067
RTAC 350 STD
3374 2998 3772 3367 4172 3767 NA NA 21904 21450 205 42
1530 1360 1711 1527 1892 1709 9936 10797 5207 1067
Notes:
1. Operating weight includes refrigerant and water.
2. Shipping weight includes refrigerant.
3. All weights +/- 3%.
