32 RTAD-SVX01F-E4
Installation - Mechanical
Figure 7 - RTAD 145HE - 150HE - 165SE - 180SE
Single Pump Available Static Pressure
1 = LRN 208-13/5.5
2 = LRN 208-14/7.5
3 = SIL 208-16/11
4 = SIL 208-17/15
Figure 8 - RTAD 145HE - 150HE - 165SE - 180SE
Dual pump Available static pressure
1 = JRN 208-13/5.5
2 = JRN 208-14/7.5
3 = DIL 208-16/11
4 = DIL 208-17/15
1
2
3
4
kPa
l/s
kPa
l/s
