60 RTAD-SVX01F-E4
Installation - Electrical
Index Network Variable SNVT Type
0 nciLocation SNVT_str_asc(36)
1 nciChillerEnable SNVT_switch(95)
2 nciMinOutTm SNVT_time_sec(107)
3 nciSndHrtBt SNVT_time_sec(107)
4 nciCapacityLim SNVT_lev_percent(81)
5 nciCoolSetpt SNVT_temp_p(105)
6 nciMode SNVT_hvac_mode(108)
7 nciHeatSetpt SNVT_temp_p(105)
8 nciDefaults SNVT_switch(95)
9 nciRcvHrtBt SCPTmaxRcvTime(48)
10 nciRefrigerant UCPT_refrig_type
11 nciMfgLocation UCPT_manufacturing_location
12 nciChillerType UCPT_chiller_type
13 nciDevMajVer SCPTdevMajVer(165)
14 nciDevMinVer SCPTdevMinVer(166)
17 nviChillerEnable SNVT_switch(95)
18 nviCoolSetpt SNVT_temp_p(105)
19 nvoOnOff SNVT_switch(95)
20 nvoActiveSetpt SNVT_temp_p(105)
21 nviCapacityLim SNVT_lev_percent(81)
22 nviMode SNVT_hvac_mode(108)
23 nviHeatSetpt SNVT_temp_p(105)
24 nvoActualCap SNVT_lev_percent(81)
25 nvoCapacityLim SNVT_lev_percent(81)
26 nvoLvgChWTemp SNVT_temp_p(105)
27 nvoEntChWTemp SNVT_temp_p(105)
28 nvoEntCndWTemp SNVT_temp_p(105)
29 nvoLvgCndWTemp SNVT_temp_p(105)
30 nvoAlarmDescr SNVT_str_asc(36)
31 nvoChillerStat SNVT_chlr_status(127)
32 nviRequest SNVT_obj_request(92)
33 nvoStatus SNVT_obj_status(93)
Index Network Variable SNVT Type
34 nviTraneVar2 UNVT
35 nvoTraneVar9 UNVT
36 nvoStatusOutputs SNVT_state(83)
37 nvoCprsrsRunning SNVT_state(83)
38 nvoCondFans SNVT_state(83)
39 nvoEvapWtrPump SNVT_switch(95)
40 nvoEvapWtrFlow SNVT_switch(95)
41 nvoCondWtrPump SNVT_switch(95)
42 nvoCondWtrFlow SNVT_switch(95)
43 nvoOutdoorTemp SNVT_temp_p(105)
44 nvoUnitVoltage UNVT_3phase_volt
45 nvoEvapRfgtPrsC1 SNVT_press_f(59)
46 nvoEvapRfgtPrsC2 SNVT_press_f(59)
47 nvoEvapRfgtTmpC1 SNVT_temp_p(105)
48 nvoEvapRfgtTmpC2 SNVT_temp_p(105)
49 nvoCondRfgtPrsC1 SNVT_press_f(59)
50 nvoCondRfgtPrsC2 SNVT_press_f(59)
51 nvoCondRfgtTmpC1 SNVT_temp_p(105)
52 nvoCondRfgtTmpC2 SNVT_temp_p(105)
53 nvoAirFlowPctC1 SNVT_lev_percent(81)
54 nvoAirFlowPctC2 SNVT_lev_percent(81)
55 nvoOilTempA SNVT_temp_p(105)
56 nvoOilTempB SNVT_temp_p(105)
57 nvoOilTempC SNVT_temp_p(105)
58 nvoOilTempD SNVT_temp_p(105)
59 nvoCurrentA UNVT_3phase_current
60 nvoCurrentB UNVT_3phase_current
61 nvoCurrentC UNVT_3phase_current
62 nvoCurrentD UNVT_3phase_current
63 nvoStartsRunTmA UNVT_starts_runtime
64 nvoStartsRunTmB UNVT_starts_runtime
65 nvoStartsRunTmC UNVT_starts_runtime
66 nvoStartsRunTmD UNVT_starts_runtime
Table 39 - Network Variable List
