Page #10 background imageLoading...
Page #10 background image
10 RTAD-SVX01F-E4
General Information
Table 5 - General Data RTAD Standard Low Noise with Night Noise Set Back option
Size 085 100 115 125 145 150 165 180
Compressor Quantity 22222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85 100/85 100/100
Evaporator
Evaporator Model EG120 EG140 EG170 EG200 EG200 EG200 EG250 EG250
Water Storage (l) 106 270 222 204 204 204 415 415
Minimum Flow (l/s) 4.1 6.0 7.3 8.8 8.8 8.8 11.6 11.6
Maximum Flow (l/s) 17.3 20.8 24.8 30.7 30.7 30.7 38.0 38.0
Condenser
Qty of Coils 22222222
Coil Length (mm) 2743 3658 3658 3658 4572 4572 5486 5486
Coil Height (mm) 1626 1626 1626 1626 1626 1626 1626 1626
Fin series (Fins/ft) 192 192 192 192 192 192 192 192
Number of Rows 3/3 2/2 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 2/2 3/3 3/3 3/3 4/4 4/4 5/5 5/5
Diameter (mm) 762 762 762 762 762 762 762 762
Total Air Flow (m
3
/s) 13.4 20.5 19.3 19.3 25.0 25.0 30.7 30.7
Nominal RPM 550 550 550 550 550 550 550 550
Tip Speed (m/s) 21.9 21.9 21.9 21.9 21.9 21.9 21.9 21.9
Motor kW (kW) 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05
Min Starting/Oper Ambient (2)
Standard Unit (°C) 00000000
Low Ambient Unit (°C) -18 -18 -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
22222222
% Min. Load (3) 17 17 17 17 17 17 17 17
Refrigerant Charge (1) (kg) 24/24 30/32 35/36 36/37 44/48 44/48 61/59 61/61
Oil Charge (1) (l) 6/6 7/7 9/9 10/10 10/10 10/10 15/11 15/15
Operating Weight (4) (kg) 2660 3205 3655 3670 4310 4520 5490 5525
Shipping Weight (4) (kg) 2554 2938 3433 3468 4107 4317 5073 5108
Table 6 - General Data RTAD High Efficiency Low Noise with Night Noise Set Back option
Size 085 100 115 125 145 150
Compressor Quantity 222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85
Evaporator
Evaporator Model EG140 EG170 EG200 EG200 EG250 EG250
Water Storage (l) 270 222 204 204 415 415
Minimum Flow (l/s) 6.0 7.3 8.8 8.8 11.6 11.6
Maximum Flow (l/s) 20.8 24.8 30.7 30.7 38.0 38.0
Condenser
Qty of Coils 222222
Coil Length (mm) 3658 3658 4572 4572 5486 5486
Coil Height (mm) 1626 1626 1626 1626 1626 1626
Fin series (Fins/ft) 192 192 192 192 192 192
Number of Rows 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 3/3 4/4 4/4 5/5 5/5
Diameter (mm) 762 762 762 762 762 762
Total Air Flow (m
3
/s) 19.2 19.2 24.9 25.0 30.6 30.6
Nominal RPM 550 550 550 550 550 550
Tip Speed (m/s) 21.9 21.9 21.9 21.9 21.9 21.9
Motor kW (kW) 1.05 1.05 1.05 1.05 1.05 1.05
Min Starting/Oper Ambient (2)
Standard Unit (°C) 000000
Low Ambient Unit (°C) -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
222222
% Min. Load (3) 17 17 17 17 17 17
Refrigerant Charge (1) (kg) 32/34 35/36 42/45 42/45 59/61 59/61
Oil Charge (1) (l) 6/6 7/7 10/10 10/10 11/11 11/11
Operating Weight (4) (kg) 3340 3370 4005 4000 5440 5445
Shipping Weight (4) (kg) 3073 3148 3802 3797 5023 5028
Notes:
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(3) Percent minimum load is for total machine at 10°C (50F) ambient and 7°C (44F) leaving chilled water temp. Not each individual circuit
(4) Weights with aluminium fins, power disconnect switch, isolators and pressure gauges
No. Of independent
Refrigerant Circuits
No. Of independent
Refrigerant Circuits
