RTAD-SVX01F-E4 17
General Information
Table 18 - General Data RTAD FC High Efficiency
Unit Size 085 100 115 125 145 150
Number of Compressors 222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85
Evaporator
Evaporator Model EG 140 EG 170 EG 200 EG 200 EG 250 EG 250
Water Storage (l) 270 222 204 204 415 415
Minimum Flow (l/s) 6 7.3 8.8 8.8 11.6 11.6
Maximum Flow (l/s) 20.8 24.8 30.7 30.7 38 38
Free-Cooler
Number of Coils 111111
Fin series (Fins/ft) 152 122 152 152 152 152
Number of Rows 465555
Water Storage (l) 481 538 531 531 806 806
(Evap+Free-Cooler)
Condenser
Number of Coils 222222
Fin series (Fins/ft) 192 192 192 192 192 192
Number of Rows 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 4/4 4/4 5/5 6/5 6/6
Diameter (mm) 762 762 762 762 762 762
Total Air Flow (m
3
/s) 20.8/15.1 23.5/17.2 26/18.9 28.9/21.2 34.1/24.8 34.7/25.4
Nominal Speed (rpm) 935/740 935/740 935/740 935/740 935/740 935/740
Motor kW (kW) 1.7/0.85 1.7/0.85 1.7/0.85 1.7/0.85 1.7/0.85 1.7/0.85
(°C) -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
222222
% Min. Load (3) 17 17 17 17 17 17
Weight. Capacities & Dimensions
Refrigerant Charge (1) (kg) 32/34 35/36 42/45 42/45 59/61 59/61
Oil Charge (1) (l) 6/6 7/7 10/10 10/10 11/11 11/11
Operating Weight (4) (kg) 4627 5106 5905 6000 7834 7889
Shipping Weight (4) (kg) 3875 4345 5170 5265 6615 6670
Length (mm) 4850 4850 5770 5770 6810 6810
Width (mm) 2420 2420 2420 2420 2460 2460
Height (mm) 2605 2605 2645 2645 2745 2745
(mm) 139.7 139.7 139.7 139.7 168.3 168.3
Water Connection Type Victaulic Victaulic Victaulic Victaulic Victaulic Victaulic
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s wind across the condenser
(3) Percent minimum load is for total machine at 10°C ambient and 7°C leaving chilled water temp. Not each individual circuit.
(4) Weights with aluminium fins, power disconnect switch, isolators and pressure gauges
Min Starting/
Oper Ambient(2)
No. Of independent
Refrigerant Circuits
Water Connection
Diameter
