Trane RTAD 100 User Manual

Installation - Mechanical
RTAD-SVX01F-E4 31
Figure 5 - RTAD 115HE - 125HE - 145SE - 150SE
Single pump available static pressure
1 = LRN 208-13/5.5
2 = LRN 208-14/7.5
3 = SIL 208-16/11
4 = SIL 208-17/15
Figure 6 - RTAD 115HE - 125HE - 145SE - 150SE
Dual pump available static pressure
1 = JRN 208-13/5.5
2 = JRN 208-14/7.5
3 = DIL 208-16/11
4 = DIL 208-17/15
1
2
3
4
kPa
l/s
1
2
3
4
kPa
l/s
