RTAD-SVX01F-E4 61
Installation - Electrical
In many cases, the Trane user-
defined types contain standard
network
variable types (SNVTs) to make
them easy to understand.
User defined types
This appendix includes
❏ User-defined network variable
types
❏ User-defined configuration
property types
These user-defined types have been
created by Trane for use by Trane
controllers.
User-defined network variable types
(UNVTs)
UNVT_purge_information
Structure definition
Field in structure Byte Bit definition Description
SNVT_state Byte 0 (MSB) Bits 0-7 (MSB) Validity of bits 8-15 (1=Valid)
Bit 8 Refrigeration Circuit On (1)
Bit 9 Pumping Out (1)
Bit 10 Regenerating (1)
Bits 11-15(LSB) Not Used
SNVT_time_f Byte 1-2 (LSB)
UNVT_starts_runtime
Structure definition
Field in structure Definition
SNVT_count_f Compressor Starts
SNVT_time_f Compressor Run Time
SUNVT_3phase_current
Structure definition
Field in structure Definition
SNVT_amp_ac L1 Current (Amps)
SNVT_amp_ac L2 Current (Amps)
SNVT_amp_ac L3 Current (Amps)
SNVT_lev_percent L1 Current (%RLA)
SNVT_lev_percent L2 Current (%RLA)
SNVT_lev_percent L3 Current (%RLA)
UNVT_3phase_volt
Structure definition
Field in structure Definition
SNVT_volt_ac AB Voltage
SNVT_volt_ac BC Voltage
SNVT_volt_ac CA Voltage
Purge 24 Hour
Pumpout Average
