Module Power and Miscellaneous I/O
78 RTHC-SVD01B-EN
J7-1 and J7-2 Heat Sink Temperature
Sensor (Solid State
Starters only)
Refer to solid state starter service bulletin.
J7-3 and J7-4 Starter Fault Relay (Solid
State Starters only)
Refer to solid state starter service bulletin.
J10-1 to J10-3 Run contact Open: 115 VAC - Normally open at start-up,
Close: 0VDC
Use Starter Dry Run under Service Tests to confirm
operation.
J10-1 to
J4-2
Jumper Required on Across the Line Starters with modules
of X13650453-07 (software revision -07) or later.
J12-1 to J12-3 Shorting contact Open: 115 VDC - Normally open at start-up.
Close: 0VDC
Use Starter Dry Run under Service Tests to confirm
operation.
J14-1 to J14-3 Transition contact Open: 115 VDC - Normally open at start-up,
Close: 0VDC
Use Starter Dry Run under Service Tests to confirm
operation.
Table 13-5: Starter Module Nominal Terminal Voltages (1U2)
Terminal Designation Description of Circuit Normal Terminal Voltages for Various Conditions
