Accessories
Table 1. Accessories
Model Number Description Use with
BAYHANG Horizontal Hanging Kit All Furnaces
BAYLIFTB Dual Return Kit (B size extension) B Cabinet Furnaces
BAYLIFTC Dual Return Kit (C size extension) C Cabinet Furnaces
BAYLIFTD Dual Return Kit (D size extension) D Cabinet Furnaces
BAYBASE205 Downflow Subbase All Furnaces in Downflow orientation
BAYSF1165AA
(a)
1” SlimFit Box with MERV 4 Filter All Furnaces
BAYSF1255BA 1” SlimFit Filter and Insulated Frame All furnaces when used in side return
application
B Cabinet furnaces only when in bottom return
application
FLRSF1255 1” Filter replacement (Qty 12) BAYSF1255BA
BAYVENT600A Internal venting kit B, C, and D Furnaces in Downflow orientation
BAYVENT800B Masonry Chimney Vent Kit All furnaces
BAYSWT20AHALTAA High Altitude Pressure Switch Kit S8B1A026M2P*
BAYSWT21AHALTAA High Altitude Pressure Switch Kit S8B1A040M3P*, S8B1B040M2P*
BAYSWT15AHALTAA High Altitude Pressure Switch Kit S8B1B060M3P*, S8B1B060M4P*,
S8B1B080M4P*
BAYSWT14AHALTAB High Altitude Pressure Switch Kit S8B1C080M5P*, S8B1C100M5P*,
S8B1D120M5P*
BAYLPSS400* Propane Conversion Kit with Stainless Steel
Burners
All Furnaces except S8B1A026
BAYLPSS410A Propane Conversion Kit with Stainless Steel
Burners
S8B1A026 Furnace only
PIP02095 U fitting for gas piping All Furnaces for right hand gas entry
(a)
Airflow greater than 1600 CFM requires dual returns
Document Pack Contents
Item Qty. Description
SSAAFFEETTYY WWAARRNNIINNGG
Onlyqualified personnelshould installand servicethe equipment.The installation,starting up,and servicingof heating,ventilating, andair-conditioning
equipmentcan behazardous andrequires specificknowledge andtraining. Improperlyinstalled, adjustedor alteredequipment byan unqualifiedperson
couldresult indeath orserious injury.When workingon theequipment, observeall precautionsin theliterature andon thetags, stickers,and labelsthat
areattached tothe equipment.
May 2020
1188--CCEE0099DD11--11EE--EENN
Upow/Downow/Horizontal Left/Right
Gas-Fired, Single Stage Induced Draft Furnaces with High
Efciency Motor
UUppffllooww,, DDoowwnnffllooww,, HHoorriizzoonnttaallRRiigghhtt//LLeefftt
Single Stage
S8B1A026M2PSAB
S8B1A040M3PSAB
S8B1B040M2PSAB
S8B1B060M3PSAB
S8B1B060M4PSAB
S8B1B080M4PSAB
S8B1C080M5PSAB
S8B1C100M5PSAB
S8B1D120M5PSAB
NN oottee::This installer’s Guideis used for multiple furnace families. Models
may have a“T” in the12th digit designating theymeet California less
than 40ng/J (NOx) emissions requirements.
NN oottee:: Graphics inthi s document are for
representation only. Actual model may
differ inappearance.
Installer’s Guide
1 1 Plug — Gas
2 1 Installer’s Guide
3 1 Service Facts
4 1 Owner Guide
5 1 Limited Warranty
6 2 Tinnerman Clips (not pictured)
Note: Tinnerman Clips should be
kept with unit and are used
if the door panel flange hole
(s) becomes stripped.
