Trane SCIH User Manual

SXIH-SVX01C-EN 11
Installation
Dimensions and Weights
Figure 1. SCIJ050 (5-ton unit) & SCIH075 (7.5-ton unit)
CONDENSER COIL
FORKLIFT ACCESS
2.76
74.80
24.90
A
BC15.43
D
18.86
E
2.76
74.80
24.90
34.25
0.75
5 & 7.5 tons
back view
front view
side view
CONDENSER
RETURN
RETURN
AIR
SIDE
ACCESS
SIDE
ACCESS
SUPPLY
AIR
SUPPLY
AIR
CONDENSER
DISCHARGE
31.50
13.64
2.74
Table 1. SCIH/SCIJ unit dimensions & weights, in-lbs.
Unit Size A B C D E Ship Wgt. Oper. Wgt.
5 & 7.5 ton 56.69 20.63 20.63 18.92 18.92 960 881
10 ton — — — — — 1333 1241
15 ton — — — — — 1480 1388
dimensions and weights
