MULTISTAGE ELECTRONIC THERMOSTAT
Pub. No. 18-HD28D1-1
Table 2. Thermostat Installer Setup Options.
Installer
Setup Number
Factory-Setting
Other Choices
(Press ▲ or ▼ key to change)
Select Display Description Display Description
Fan operation 02 00 Coventional application
where equipment
controls fan operation in
heat mode
01 Application where thermosta
t
controls fan operation in hea
t
mode
Number of heating
stages.
03 02 2 heating staes 00 or
01
00—no heating
01—1 heating stage
Stage 1 heating cycle rate 04 03 3—3 cph recommended
5, 6 or 9 cph—not
recommended
05, 06
or 09
05—5 cph
06—6 cph
09—9 cph
Stage 2 heating cycle rate 05 05 5—5 cph recommended
5, 6 or 9 cph—not
recommended
03, 06,
or 09
03—3 cph
06—6 cph
09—9 cph
Number of cooling stages 08 01 1 cooling stage 00 or
02
00—no cooling
02—2 cooling stages
Stage 1 cooling cycle rate 09 03 3—3 cph recommended
2 or 5 cph—not
recommended
02 or
05
02—2 cph
05—5 cph
Stage 2 cooling cycle rate 10 03 3—3 cph recommended
2 or 5 cph—not
recommended
02 or
05
02—2 cph
05—5 cph
System setting
adjustment
12 00 Automatic changeover 01 or
02
01—Manual changeover
02—Auto Only
Degree temperature
display
14 00 Temperature displays
in °F
01 Temperature displays in °C
Extended fan operation in
heating
a
19 00 No extended fan
operation after the call
for heat ends
1, 2 or
3
1—Fan operation exends 30
seconds after the call ends
2—Fan operation exends 60
seconds after the call ends
3—Fan operation exends 90
seconds after the call ends
Extended fan operation in
cooling
20 00 No extended fan
operation after the call
for cool ends
1, 2 or
3
1—Fan operation exends 30
seconds after the call ends
2—Fan operation exends 60
seconds after the call ends
3—Fan operation exends 90
seconds after the call ends
Outdoor temperature
display (select models)
24 00 No outdoor temperature
displays.
01 Outdoor temperature is
displayed. Needs a
TAYSENS100A Outdoor
Sensor
Comfort-R Enable 28 00 No fan delay 01 or
02
01—30 seconds (maximum
delay)
02—15 seconds (maximum
delay)
a
Available if Installer Setup Number 02 is set to 01.
