Trane TR1 6002 User Manual

10
380/460 Volt Input
208/230 Volt Input
600 Volt Input
200-240 V drives are suitable for use on a circuit capable of supplying a
maximum of 100,000 A RMS (symmetrical), 250 V maximum.
380-460 V drives are suitable for use on a circuit capable of supplying a
maximum of 100,000 A RMS (symmetrical), 500 V maximum.
550-600 V drives are suitable for use on a circuit capable of supplying a
maximum of 100,000 A RMS (symmetrical), 600 V maximum.
Input Fuses
CAUTION
Branch Circuit Fuses Required!
All drives must be protected with branch circuit
fuses in accordance with the National Electrical
Code. Failure to provide branch circuit fuses in
accordance with the NEC may result in
equipment or property damage.
To comply with UL508C, input fuses shown in the tables below must be
installed in the power supply to drives which are 208 V above 30 hp,
and 380/460 V and 600 V drives above 75 hp. The fuse ratings in the
tables below are the recommended maximum ratings.
NOTE
Any UL listed Class T fuse with equivalent
voltage and current rating may be used in place
of JJS and JJN fuse types.
Trane recommends input fuses on all drives. If specified as a drive
option, input fuses will be installed by The Trane Company in an
enclosure external to the drive, which may include other optional
features. If not supplied, they must be provided by the drive installer as
part of installation.
TR1 Type
Maximum Fuse
Rating (Amps) Bussmann Type
6002 10 JJS
6003 10 JJS
6004 15 JJS
6006 20 JJS
6008 25 JJS
6011 35 JJS
6016 50 JJS
6022 60 JJS
6027 80 JJS
6032 90 JJS
6042 110 JJS
6052 150 JJS
6062 175 JJS
6072 100 JJS
6100 125 FWP
6125 175 FWP
6150 200 FWP
6175 250 FWP
6225 350 FWP
6275 400 FWP
TR1 Type
Maximum Fuse
Rating (Amps) Bussmann Type
6002 20 JJN or JJS
6003 20 JJN or JJS
6004 40 JJN or JJS
6006 50 JJN or JJS
6008 80 JJN or JJS
6011 100 JJN or JJS
6016 150 JJN or JJS
6022 200 JJN or JJS
6027 225 JJN or JJS
6032 300 JJN or JJS
6042 400 JJN or JJS
6052 200 FW X or FWH
6062 250 FW X or FWH
TR1 Type
Maximum Fuse
Rating (Amps)
Bussmann Type
6002 10 JJS
6003 15 JJS
6004 15 JJS
6006 25 JJS
6008 35 JJS
6011 45 JJS
6016 70 JJS
6022 90 JJS
6027 110 JJS
6032 125 JJS
6042 175 JJS
6052 200 JJS
6062 200 JJS
6072 250 JJS
6102 300 JJS
6122 350 JJS
6150 300 FWH
6152 300 FWH
6172 300 FWH
6175 350 FWH
6222 350 FWH
6225 400 FWH
6272 400 FWH
6275 500 FWH
6350 600 FWH
6352 600 FWH
6400 700 FWH
6500 800 FWH
6550 800 FWH
