16
BAS-SVN032B-EN
Table 7. TR170 VFD drive parameter RTAC
Parameter Number Parameter Description RTAC Setting Units
0-03 Regional Settings North America for 60 Hz, International for 50
Hz
—
0-06 Grid Type Depends on Grid Type —
0-40 [Hand on] Key on LCP Disable (0) —
1-20 Motor Power (Motor Specific) kW
1-22 Motor Voltage (Motor Specific) V
1-23 Motor Frequency (Motor Specific) Hz
1-24 Motor Current
(Motor Specific)
A
1-25 Motor Nominal Speed (Motor Specific) RPM
1-71 Start Delay 3 s
1-72 Start Function DC Hold (0) —
1-73 Flying Start Enabled (1) —
1-82
Min Speed for Function at Stop [Hz]
0.1 Hz
1-90 Motor Thermal Protection ETR Trip 1 (4) —
2-00 DC Hold/Motor Preheat Current Default Value %
2-02 DC Braking Time Default Value s
2-10 Brake Function Off (0) —
3-03
Maximum Reference 50/60
(a)
—
3-16
Reference 2 Source No function (0)
—
3-17
Reference 3 Source No function (0)
—
3-41 Ramp 1 Ramp Up Time 5 s
3-42 Ramp 1 Ramp Down Time 20 s
4-10 Motor Speed Direction Clockwise (0) —
4-12 Motor Speed Low Limit [Hz] 3 Hz
4-14 Motor Speed High Limit [Hz] 50/60
(a)
Hz
4-18 Current Limit If p122 = 380V then 115 Else 125 %
5-12 Terminal 27 Digital Input No operation (0) —
5-40 Function Relay Alarm (9) —
6-10 Terminal 53 Low Voltage 0 V
6-14
Terminal 53 Low Ref./Feedb. Value
0 —
6-15
Terminal 53 High Ref./Feedb. Value 50/60
(a)
—
14-01 Switching Frequency 5 kHz
14-12 Function at Mains Imbalance De-rate (3) —
14-20 Reset Mode Auto Reset x10 (10) —
14-21 Automatic Restart Time 30 s
14-50 RFI Filter Off (0) —
(a)
60 or 50Hz for Pueblo Production, 50Hz for Charmes production. Otherwise, set for maximum speed rating of motor/fan.
The following table defines the complete set of parameters for the TR170 VFD drives used in
IInnssttaalllliinngg TTRR117700 VVFFDD aanndd CCoommppoonneennttss
