For high load at low speed (<30% of rated speed), it is
recommended that parameter 1-17 Voltage lter time const.
is increased due to non-linearity in the inverter at low
speed.
1-14 Damping Gain
Range: Function:
120
%
*
[0 -
250 %]
The parameter stabilizes the PM motor to ensure
smooth and stable operation. The value of
damping gain controls the dynamic performance
of the PM motor. Low damping gain results in
high dynamic performance and a high value
results in a low dynamic performance. The
dynamic performance is related to the motor data
and load type. If the damping gain is too high or
low, the control becomes unstable.
1-15 Low Speed Filter Time Const.
Range: Function:
Size
related
*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too short, the control
becomes unstable. This time constant is
used below 10% rated speed.
1-16 High Speed Filter Time Const.
Range: Function:
Size
related
*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too short, the control
becomes unstable. This time constant is
used above 10% rated speed.
1-17 Voltage lter time const.
Range: Function:
Size
related
*
[0.01 - 1
s]
Machine supply voltage lter time
constant is used for reducing the
inuence
of high frequency ripples and
system resonances in the calculation of
machine supply voltage. Without this
lter,
the ripples in the currents can
distort the calculated voltage and aects
the stability of the system.
3.2.4 1-2* Motor Data I
This parameter group comprises input data from the
nameplate on the connected motor.
NOTICE
These parameters cannot be adjusted while the motor is
running.
NOTICE
Changing the value of these parameters aects the
setting of other parameters.
1-20 Motor Power
Enter the nominal motor power in kW/hp according to the motor
nameplate data. The default value corresponds to the nominal
rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Option: Function:
[2] 0.12 kW - 0.16 hp
[3] 0.18 kW - 0.25 hp
[4] 0.25 kW - 0.33 hp
[5] 0.37 kW - 0.5 hp
[6] 0.55 kW - 0.75 hp
[7] 0.75 kW - 1 hp
[8] 1.1 kW - 1.5 hp
[9] 1.5 kW - 2 hp
[10] 2.2 kW - 3 hp
[11] 3 kW - 4 hp
[12] 3.7 kW - 5 hp
[13] 4 kW - 5.4 hp
[14] 5.5 kW - 7.5 hp
[15] 7.5 kW - 10 hp
[16] 11 kW - 15 hp
[17] 15 kW - 20 hp
[18] 18.5 kW - 25 hp
[19] 22 kW - 30 hp
[20] 30 kW - 40 hp
[21] 37 kW - 50 hp
[22] 45 kW - 60 hp
[23] 55 kW - 75 hp
[24] 75 kW - 100 hp
[25] 90 kW - 120 hp
[26] 110 kW - 150 hp
1-22 Motor Voltage
Range: Function:
Size
related
*
[50 - 1000
V]
Enter the nominal motor voltage
according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
1-23 Motor Frequency
Range: Function:
Size
related
*
[20 -
400
Hz]
Select the motor frequency value from the
motor nameplate data. For 87 Hz operation
with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt
parameter 4-14 Motor Speed High Limit [Hz]
