BAS-SVX46E-EN
5
Overview
This guide provides installation, operation, and maintenance information for Tracer XM30,
XM32, XM70, and XM90 expansion modules.
Expansion modules provide additional hardware terminations when needed for Tracer UC400
and Tracer UC600 applications. Commissioning and troubleshooting is covered in a later section.
Specifications
The following table provides storage and operation specifications for the expansion modules.
Table 1. Storage and operating environment specifications
Storage
Temperature: -67°F to 185°F (-55°C to 85°C)
Relative humidity: 5% to 95% (non-condensing)
Operating
Temperature: -40°F to 158°F (-40°C to 70°C)
Humidity: 5% to 95% (non-condensing)
Power:
XM30 Input: 24 Vdc ±10%, 120 mA
XM32 Input: 24 Vdc ±10%, 100 mA
XM70 Input: 20.4–27.6 Vac (24 Vac, ±15% nominal) 50 or 60 Hz, 26 VA, (26 VA
plus a maximum of 12 VA for each binary output)
Output: 24 Vdc ±10%, device max load 600 mA
XM90 Input: 18–30 Vac (24 Vac nominal) 50 or 60 Hz, 50 VA, 2.08A max @
500mA load (on 24 Vdc output terminals), plus a maximum of 12 VA for each
binary output up to 8 total
Output: 24 Vdc ±10%, device max load 500 mA dc Class 2
Communication:
IMC, 5 Vdc, Class 2, IMC terminals
Mounting weight of controller:
XM30 Mounting surface must support .27 lb. (0.122 kg) with terminal
connectors: must support .31 lb. (0.142 kg)
XM32 Mounting surface must support .43 lb. (0.195 kg) with terminal
connectors: must support .47 lb. (0.213 kg)
XM70/XM90 Mounting surface must support 1.3 lb. (0.6 kg) with terminal
connectors: must support 1.53 lb. (0.69 kg)
Environmental rating (enclosure):
NEMA 1
Installation:
UL 840:Category 3
Pollution:
UL 840:Degree 2
Agency Compliance
• UL916 PAZX- Open Energy Management Equipment
• UL94-5V Flammability
• CE Marked
FCC Part 15, Subpart B, Class B Limit
Configurable Connections
The following tables provide input and output connection information.
