Installation

RT-SVX37B-EN 25

Example #3 Figure 28, p. 26 illustrates the circuit required

for this sensor.

Table 5 lists the temperature versus resistance coefficient

for all sensors.

Table 5. Temperature vs resistance

Temperature

Nominal

Resistance

Degrees

F°

Degrees

C°

-20° -28.9° 170.1 K - Ohms

-15° -26.1° 143.5 K - Ohms

-10° -23.3° 121.4 K - Ohms

-5° -20.6° 103.0 K - Ohms

0° -17.8° 87.56 K - Ohms

5° -15.0° 74.65 K - Ohms

10° -12.2° 63.80 K - Ohms

15° -9.4° 54.66 K - Ohms

20° -6.7° 46.94 K - Ohms

25° -3.8° 40.40 K - Ohms

30° -1.1° 34.85 K - Ohms

35° 1.7° 30.18 K - Ohms

40° 4.4° 26.22 K - Ohms

45° 7.2° 22.85 K - Ohms

50° 10.0° 19.96 K - Ohms

55° 12.8° 17.47 K - Ohms

60° 15.6° 15.33 K - Ohms

65° 18.3° 13.49 K - Ohms

70° 21.1° 11.89 K - Ohms

75° 23.9° 10.50 K - Ohms

80° 26.7° 9.297 K - Ohms

85° 29.4° 8.247 K - Ohms

90° 32.2° 7.330 K - Ohms

95° 35.0° 6.528 K - Ohms
