fully closed.
 When all outdoor units are running:
 All EXVAs are controlled according to discharge temperature.
4.6 Outdoor Fan Control
The speed of the outdoor unit fans is adjusted in steps, as shown in Table 3-4.2.
Table 3-4.2: Outdoor fan speed steps
Fan speed index
Fan speed (rpm)
8-16HP
18-22HP
24-30HP
FANA / FANB
FANA / FANB
0
0
0 / 0
0 / 0
1
120
150 / 0
120 / 0
2
150
190 / 0
150 / 0
3
170
230 / 0
170 / 0
4
190
270 / 0
190 / 0
5
210
310 / 0 (150 / 150)
210 / 0
6
230
350 / 0 (180 / 180)
230 / 0
7
250
380 / 0 (210 / 210)
250 / 0 (120 / 120)
8
270
410 / 0 (240 / 240)
270 / 0 ( 150 / 150)
9
290
280 / 280
330 / 0 (170 / 170)
10
310
320 / 320
370 / 0 (190 / 190)
11
330
360 / 360
210 / 210
12
350
400 / 400
230 / 230
13
370
440 / 440
250 / 250
14
390
480 / 480
270 / 270
15
410
520 / 520
290 / 290
16
430
560 / 560
310 / 310
17
450
600 / 600
330 / 330
18
470
640 / 640
350 / 350
19
490
680 / 680
370 / 370
20
510
720 / 720
400 / 400
21
530
750 / 750
430 / 430
22
560
780 / 780
470 / 470
23
580
800 / 800
510 / 510
24
600
840 / 840
550 / 550
25
630
880 / 880
600 / 600
26
650
910 / 880
650 / 650
27
700
910 / 910
680 / 680
28
750
940 / 910
700 / 700
29
800
940 / 940
750 / 750
30
850
980 / 940
780 / 780
31
880
980 / 980
800 / 800
32
910
1000 / 980
830 / 830
33
930
1000 / 1000
850 / 850
34
960
1020 / 1000
870 / 870
35
1000
1020 / 1020
890 / 890
36
1050
1050 / 1050
920 / 920
37
1100
1100 / 1100
950 / 950
Note:
1. For 18-22HP unit fan speed 5 to 8 and 24-30HP unit fan speed 7 to 10, when fan speed decreases, the fan speed is shown in the bracket; when fan speed
increases, the fan speed is shown without bracket.
