28
Scheduling is usually controlled by your Z-Wave system. See the instructions that came with your Z-Wave system for more information.
However, scheduling may also be controlled by the thermostat.
ÎÎ The Schedules menu is hidden by default, but may be enabled in the Installer Settings. See Enable/DisableÎtheÎSchedulesÎMenu on
page 28 for more information..
The thermostat has a 4 x 7 schedule, meaning the setpoints can be changed up to four times a day each day. Each day has a separate
schedule. Schedules may be copied from one day to another day or group of days. See CopyÎaÎDayÎSchedule on page 29 for more information.
Select Schedule
Heat and Cool
Preset:Confort
Preset:Energy Star
Done Select
Enable/Disable the Schedules Menu
Because the Schedules menu is disabled by default, you must first enable it before any scheduling can be done at the thermostat. If you want
to use your Z-Wave system for scheduling, scheduling must be disabled in the thermostat.
1. Press the MENU button.
2. Press and hold the two middle buttons simultaneously until the InstallerÎSettings menu is displayed.
3. Scroll to SystemsÎSettings and press the Select button.
4. Scroll to Sched Enable and press the plusÎ(+) button to enable scheduling or the minusÎ(-) button to disable scheduling.
ÎÎ When scheduling is enabled in the thermostat, a Y will be displayed next to SchedÎEnable. When scheduling is disabled in the
thermostat, an N will be displayed next to SchedÎEnable.
Load a Preset Schedule
There are two possible schedules that may be loaded: Preset Comfort and
Preset Energy Star. These schedules may not be changed. When a schedule
is loaded, it changes the current Heat and Cool schedule settings. You can
then edit the Heat and Cool schedule, if necessary.
ÎÎ Selecting Preset Comfort or Preset Energy Star schedules will overwrite
the current Heat and Cool schedule.
1. Press the MENU button.
2. Scroll to Schedules and press the Select button.
3. Scroll to the schedule you want to load and press the Select button.
4. Press the Yes button.
Preset Schedule Description
Preset: Comfort This is a preset schedule with mild setbacks,
designed to maintain a comfortable temperature.
Preset: Energy Star This is a preset schedule with deeper setbacks,
designed to conserve energy.
Monday Schedule
Wake 06 : 00 A 70 78
Day 08 : 00 A 70 78
Eve 04 : 00 P 70 78
Sleep 10 : 00 P 66 81
Done Select
+
-
Time Heat Cool
c
Schedules
