5.3.3 Group 2* - Equipment Settings
* If Zoning is enabled, this group will be called Group 3.
MENU ITEM
OPTIONS
[DEFAULT]
DESCRIPTION
Compressor Cooling Cycles Per Hour 2 - 6 Cph [3] Select # of cycles per hour during cooling operation
1st Stage Compressor Cooling Cycles Per Hour 2 - 6 Cph [3] Select # of cycles per hour during 1st stage cooling operation
2nd Stage Compressor Cooling Cycles Per Hour ① 2 - 6 Cph [3] Select # of cycles per hour during 2nd stage cooling operation
Compressor Heating Cycles Per Hour 2 - 6 Cph [3] Select # of cycles per hour during compressor heating operation
1st Stage Compressor Heating Cycles Per Hour 2 - 6 Cph [3]
Select # of cycles per hour during 1st stage compressor heating
operation
2nd Stage Compressor Heating Cycles Per Hour ① 2 - 6 Cph [3]
Select # of cycles per hour during 2nd stage compressor heating
operation
Indoor Heater Cycles Per Hour 2 - 6 Cph [5] Select # of cycles per hour during indoor heat operation
1st Stage Indoor Heat Cycles Per Hour 2 - 6 Cph [5] Select # of cycles per hour during 1st stage indoor heat operation
2nd Stage Indoor Heat Cycles Per Hour 2 - 6 Cph [5] Select # of cycles per hour during 2nd stage indoor heat operation
3rd Stage Indoor Heat Cycles Per Hour 2 - 6 Cph [5] Select # of cycles per hour during 3rd stage indoor heat operation
① Duty Cycles do not apply to second stage (variable range) of VSPD outdoor units
5.3.4 Group 3* - Sensor Settings
* If Zoning is enabled, this group will be called Group 4 .
MENU ITEM OPTIONS [DEFAULT] DESCRIPTION
Select Outdoor Temperature Sensor
No ODT Sensor
Thermostat ODT Sensor
Communicating ODT Sensor
Relay Panel ODT Sensor
Select the desired outdoor temperature sensor
Thermostat Humidity Sensor ① Enable, Disable
Allows the user to re-enable the on-board humidity sensor of the
1050 when a wired sensor is being used in place of the on-board
temperature sensor of the 1050
Humidity Controlling Zone ② Select a zone
Select which zone’s humidity reading will be the humidity controlling
zone. Only zones which have a temperature/humidity sensor can be
selected
① This setting is only available when the onboard temperature sensor has been disabled
② This setting is only available when zoning has been enabled and one or more 940’s are being used as zone sensors
