Trane UC SERIES User Manual

18-CD19D5-10 5
Installer’s Guide
MODEL A B C D
*DC040C924
*DC060C936
*DC080C942
17-1/2" 2-1/4" 16-1/4" 16"
*DC100C948 21" 2-1/2" 19-3/4" 19-1/2"
*DC120C960 24-1/2" 2-15/16" 23-1/4" 23"
* - First letter may be "A" or "T"
From Dwg. 21C340462 Rev. 7
*DC-C DOWNFLOW / HORIZONTAL OUTLINE DRAWING
(ALL DIMENSIONS ARE IN INCHES)

Trane UC SERIES Specifications

General

Brand	Trane
Model	UC SERIES
Category	Furnace
Language	English
