Trane UHSB User Manual

UH-SVX01A-EN 7
Location
Figure 9. Four Point Suspension-Shelf Mounted Motors Only
C
L
C
L
D6340
UNIT SIZE
048/060
072
084 & 120
096/108
132/144/156
180/204
240/280
300/360
A
17-13/16
31-9/16
26-1/16
22-13/16
21-9/16
19-1/16
15-5/16
16-9/16
2-1/2
6"
10"
3-1/2
4"
3"
1-7/8
2-1/2
4-1/2
BC
11-11/16
A
1-3/4
C
1"
BB
1-3/4
C
4 PT. SUSPENSION
USE 3/8-16
THREADED RODS
(4 LOCATIONS)
