8 UH-SVX01A-EN
Location
Figure 10. Forced Hot Water
RETURN
SUPPLY
PET COCK
(SYSTEM VENT)
GATE VALVE
GATE VALVE
DRAIN VALVE
"FORCED HOT WATER"
D-6056
