Installation
25UNT-SVX10G-E4
Figure 16 - Condensate pump option for ZN control
1 = Condensate tray
2 = Condensate level sensor
3 = Condensate tube suction
4 = Condensate tube discharge
5 = Vent
It is recommended to secure connection between the tube and the drain with a clamp
or a collar.
5
3
1
2
4
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 25
