Installation
UNT-SVX10G-E426
Figure 17 - Condensate drainage with condensate pump for on/off (GP) control or ZN
control
A = Position the vent upwards
1 = Water
2 = Air
B = No negative discharge
WARNING !
X
A
1
1
2
B
60 mm
10 mm/m
L
10 mm/m
H
