UNT-SVX10G-E410
Installation
Table 4 - General data - FED with inlet/discharge air connections (Dia. 200mm) and EU3 filter
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 50Pa Unit size 200 300 400 500 600
Airflow (1) (m3/h) 104 376 449 827 963
S
tandard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total / sensible cooling capacity (1) (kW) 0.65 / 0.5 2.3 / 1.7 3 / 2.2 4.2 / 3.2 6.8 / 5
EER / Eurovent Energy class (2) 84 / B 100 / A 128 / A 78 / B 110 / A
W
ater flow (1) (l/s) 0.031 0.11 0.14 0.2 0.33
Water pressure drop (1) (kPa) 1.2 8.1 14.4 34.7 25.8
W
ater content (l) 0.6 1.3 1.5 1.5 2.8
W
ater connection 1/2" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 0.81 3 3.6 5.1 7.6
COP / Eurovent Energy class (2) 98 / A 191 / A 148 / A 86 / B 119 / A
Water flow (1) (l/s) 0.031 0.11 0.14 0.2 0.33
Water pressure drop (1) (kPa) 0.97 7.1 11.6 20.3 22.4
E
lectric heater (option)
Electric heater (W) 500 500 / 750 1000 / 3000 1000 / 3000 1000 / 3000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed (speeds 1/3/5) (W) 3.7/8.7/19 4.8/18/43 6/25/46 23/69/100 25/76/109
A
bsorbed current (min/max) (A) 2.2 2.2/3.3 4.3/13 4.3/13 4.3/13
Fan motor
Maximun external static pressure (Pa) 50 70 70 70 70
Sound levels
Supply sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 32/38/47 39/46/56 36/52/58 47/57/60 47/57/60
Return sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 35/40/48 40/47/56 36/52/58 50/60/63 50/60/63
Radiated sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 29/34/42 31/37/46 32/46/51 40/50/53 40/50/53
NR Level (speeds 2 / 3 / 5) (4) 13/17/25 19/26/36 16/34/39 27/37/40 27/37/40
NC Level (speeds 2 / 3 / 5) (4) 10/15/24 17/25/34 14/32/37 25/35/38 25/35/38
Voltage range
Minimum voltage (V) 2.3 2.6 3 3.5 3
Maximum voltage (V) 5.8 7.6 977
Speed 1/5/6 -> speed low/medium/high
(1) At medium speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed (low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent FC Certification For 400/500/600 as per voltages declared to Eurovent.
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 20dB
