7UNT-SVX10G-E4
Installation
Speed at ESP = 0Pa Unit size 101 103 203 204 304 306 406 408 508 512 612 721
Airflow (1) (m3/h) 188 271 321 415 438 642 642 1004 1110 1329 1411 2031
Standard coil,
cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total/sensible
cooling capacity (1) (kW) 1.3/0.97 1.7/1.3 1.6/ 1.3 1.9/1.6 2.8/2.1 3.7/2.8 4.1/3.1 5.5/4.3 4.9/3.8 5.5/4.4 8.8/6.6 11.1/1.5
EER/Eurovent
E
nergy class (2) 50/F 53/E 45/F 45/F 53/E 58/E 65/E 58/E 50/F 33/G 49/F 39/F
Water flow (1) (l/s) 0.062 0.081 0.076 0.091 0.13 0.18 0.2 0.26 0.24 0.26 0.42 0.53
Water pressure
d
rop (1) (kPa) 16 24.8 5.8 8 13 21.6 25.3 42.9 45.8 55.3 40.9 42.5
Water content (l) 0.5 0.5 0.6 0.6 1.3 1.3 1.5 1.5 1.5 1.5 2.8 3.3
Water connection 1/2" ISO R7 female gas 3/4" ISO R7 female gas
Standard coil,
heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.5 1.9 2.3 2.8 3.5 4.8 5.2 7.3 6.8 7.8 10.2 14.2
COP/Eurovent
E
nergy class (2) 55/E 59/E 66/E 63/E 67/E 75/D 78/D 72/D 64/E 45/F 54/E 49/F
Water flow (1) (l/s) 0.062 0.081 0.076 0.091 0.13 0.18 0.2 0.26 0.24 0.26 0.42 0.53
Water pressure
drop (1) (kPa) 13.1 20.7 4.8 6.7 13.6 23 20.6 35.2 38.7 46.8 35.6 39.5
Electric heater
(option)
Electric heater (W) NA 500 500/750 500/1000 500/1500 500/1500 500/1500 1500/4000 1500/3000 1500/4000 1500/4000 1500/4000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed
(speeds 1/3/5) (W) 11/16/27 18/25/40 19/26/41 23/37/54 26/42/61 36/58/82 36/59/82 53/87/118 53/87/124 118/139/164 119/145/171 152/184/289
Absorbed current
(min/max) (A) - 2.2 2.2/3.3 2.2/4.3 2.2/6.5 2.2/6.5 2.2/6.5 6.5/17.4 6.5/13 6.5/17.4 6.5/17.4 6.5/17.4
Fan motor
Maximun external
static pressure (Pa) 40 60 60 60 90 90 90 90 90 90 90 90
Sound levels
Sound power level
(speeds 2/3/5) (3) (dB(A)) 28/32/42 40/47/54 41/47/54 39/49/ 56 38/47/53 43/53/59 46/55/61 45/54/60 45/56/61 52/59/64 50/58/63 49/64/53
Sound pressure level
(speeds 2/3/5) (4) (dB(A)) 19/23/33 31/38/45 32/38/45 30/40/47 29/38/44 34/44/50 37/46/52 36/45/51 36/47/52 43/50/55 41/49/54 40/55/44
NR Level
(speeds 2/3/5) (4) 17/17/25 28/34/40 29/34/40 27/37/43 25/34/40 30/41/47 34/43/48 31/40/46 32/43/48 36/45/51 35/43/49 36/50/39
NC Level
(speeds 2/3/5) (4) 16/15/23 26/33/39 27/33/39 26/35/41 23/32/39 29/39/45 32/41/46 29/38/44 30/41/46 35/44/49 34/41/47 34/49/38
Speed 1/3/5 -> speed low/medium/high
(1) At high speed acc. to Eurovent conditions
(2) EER Eurovent ratio and class definition (speed low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent FC Certification
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 9dB
General data
Table 1 - General data - FCD without air connections
230V/50Hz/1pH, Reversible coil, 2 Pipes
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 7
