UNT-SVX10G-E48
Installation
Table 2 - General data - FCD with inlet/discharge air connections (Dia. 200mm) and EU3 filter
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 50Pa Unit size 204 (*) 304 (*) 306 406 408 508 512 612 721
A
irflow (1) (m3/h) 145 152 402 400 544 585 864 869 1990
S
tandard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta
T
otal/sensible cooling capacity (1) (kW)
0.84/0.
68
1.2/0.8
5
2
.6/2 2.9/2.1 3.7/2.7 3.3/2.4 4.3/3.3 6.3/4.5 11/8.4
EER/Eurovent Energy class (2) 24/E 28/D 42/C 47/C 41/C 35/D 32/D 45/C 40/D
Water flow (1) (l/s) 0.04 0.056 0.13 0.14 0.18 0.16 0.2 0.3 0.53
Water pressure drop (1) (kPa) 1.9 2.5 11.6 13.5 20.7 22.2 35.2 22.1 41
W
ater content (l) 0.6 1.3 1.3 1.5 1.5 1.5 1.5 2.8 3.3
Water connection 1/2" ISO R7 female gas 3/4" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.2 1.4 3.3 3.5 4.5 4.2 5.7 6.9 14
COP/Eurovent Energy class (2) 32/D 32/D 53/C 56/C 50/C 45/C 42/C 49/C 50/C
Water flow (1) (l/s) 0.04 0.056 0.13 0.14 0.18 0.16 0.2 0.3 0.53
Water pressure drop (1) (kPa) 1.5 2.5 10.1 10.9 16.7 18.7 29.7 19.1 38
Electric heater (option)
Electric heater (W)
500/
1000
500/
1500
500/
1500
500/
1500
1500/
4000
1500/
3000
1500/
4000
1500/
4000
1500/
4000
Power supply (V-Ph-Hz)
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-50
Power absorbed (speeds 1/3/5) (W)
23/37
/54
26/42
/61
36/58
/82
36/59
/82
53/87
/118
53/87
/124
118/13
9/164
119/14
5/171
146/254/283
Absorbed current (min/max) (A) 2.2/4.3 2.2/6.5 2.2/6.5 2.2/6.5 6.5/17.4 6.5/13 6.5/17.4 6.5/17.4 6.5/17.4
Fan motor
Maximun external static pressure (Pa) 50 70 70 70 70 70 70 70 70
Sound levels
Supply sound power level (speeds
2/3/5) (3)
(dB(A))
39/45/
47
38/46/
47
45/50/
54
42/48/
51
42/49/
52
46/53/
57
50/54/
58
47/50/
54
39/43/54
Return sound power level (speeds
2/3/5) (3)
(dB(A))
42/48/
50
43/49/
51
47/52/
55
45/50/
53
40/47/
51
51/56/
59
53/56/
59
50/53/
56
42/46/67
Radiated sound power level
(speeds 2/3/5) (3)
(dB(A))
31/40/
44
31/40/
43
33/42/
47
33/41/
47
42/48/
53
42/48/
53
44/48/
53
44/49/
53
37/41/52
NR Level (speeds 2/3/5) (4)
20/25/
27
18/25/
27
24/31/
34
24/31/
34
22/30/
34
27/33/
36
31/34/
37
27/30/
33
20/24/34
NC Level (speeds 2/3/5) (4)
18/23/
25
16/23/
26
23/29/
33
23/29/
32
20/28/
33
25/32/
35
29/32/
35
26/28/
32
18/22/
32
Speed 1/5/6 -> speed low/medium/high
(1) At medium speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed (low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent FC Certification
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 20dB
(*) FCD 204/304 performance at speeds 1/4/5 : sound power at speeds 2/3/4
