Trane UniTrane FCD User Manual

Installation
5UNT-SVX10G-E4
Unit identification
Units arrive on site with an
identification sticker with
pictograms, which clearly indicates
important information such as the
customer order number, job name,
unit model size, coil type, presence
of an electric heater, motor type,
unit handing, speed wiring, and so
on. (See Figure 1)
Figure 1 - Unit identification sticker
2
1
8
9
10
7
345
FCD204
FCD204AWH5RJW1WABWWW AAWWW2EGW
UK CO6 2NS
1-3-5
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 5
