Trane UniTrane FCD User Manual

Installation
UNT-SVX10G-E440
External static pressure and airflow curves
Figure 32 - External Static Pressure - FCD 101 with G3 filter
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
Figure 33 - External Static Pressure - FCD 103 with G3 filter
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
0
10
20
30
40
50
60
70
80
90
100
050100150200250300
1
D1
D2
2
3
4
5
6
m3/h
Pa
0
10
20
30
40
50
60
70
80
90
100
050100150200250300350
D1
D2
1
2
3
4
5
6
m3/h
Pa
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 40
