Trane UniTrane FCD User Manual

31UNT-SVX10G-E4
Installation
Figure 20 - FED 300 Airflow operating range
A = Airflow pressure drop system curve
B = Standard selection operating system zone
Figure 21 - FED 300 with Electric Heater 500 W - 7500 W - 1000 W
A = 160 m
3
/hr minimum airflow for 1000 W
B = Not allowed operating system
C = Special selection operating system zone
D = Airflow pressure drop system curve
E = Standard selection operating system zone
Figure 22 - FED 300 with Electric Heater 1500 W - 2000 W
A = 320 m
3
/hr minimum airflow for 2000 W
B = Not allowed operating system zone
C = Special selection operating system zone
D = Airflow pressure drop system curve
E = Standard selection operating system zone
300 400 500 600 700 800
m
3/h
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 31
