Installation
UNT-SVX10G-E442
Figure 36 - External Static Pressure - FCD 304 with G3 filter
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
Figure 37 - External Static Pressure - FCD 306 with G3 filter
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
0
10
20
30
40
50
60
70
80
90
100
0100200300400500600
D1
D2
1
2
3
4
5
6
m3/h
Pa
0
10
20
30
40
50
60
70
80
90
100
0100200300400500600700800
D1
D2
12 3 4 5 6
m3/h
Pa
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 42
