Installation
UNT-SVX10G-E448
Figure 48 - External Static Pressure - FED 500
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
Figure 49 - External Static Pressure - FED 600
D1 = Discharge plenum only, ø200 mm air duct connection(s)
D2 = Discharge plenum + return plenum, ø200 mm air duct connections(s)
0
10
2
0
3
0
40
5
0
60
70
8
0
90
1
00
0
200 400 600 800 1000 1200 1400 1600 1800
0
10
20
30
4
0
5
0
60
70
80
9
0
100
0 200 400 600 800 1000 1200 1400
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 48
