On the unit with plenum at the inlet,
To remove the filter (1):
1) Unscrew the two tabs (4) and
push them backwards.
2) Pull down the filter using a
screwdriver.
To put the filter back, hold the filter
at the top of the frame with one
hand. Push to clip the filter back
into place at the bottom with the
other hand.
Figure 59 - Handling the filter - unit with inlet air connection
4
Maintenance
UNT-SVX10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 56
