RT-SVX23D-EN 5
Model Number Descriptions
DIGIT 1 - Unit Function
W = Packaged Heat Pump
DIGIT 2 - Efficiency
S = Standard Efficiency
DIGIT 3 - Airflow
C = Convertible
DIGITS 4,5,6 - Nominal Gross
Cooling Capacity (MBh)
036 = 3 Ton
048 = 4 Ton
060 = 5 Ton
072 = 6 Ton
090 = 7½ Ton
120 = 10 Ton
DIGIT 7 - Major Design Sequence
A= First
E=R410A
DIGIT 8 - Unit Voltage
1 = 208-230/60/1
3 = 208-230/60/3
4 = 460/60/3
W = 575/60/3
DIGIT 9 - Unit Controls
R = ReliaTel™Microprocessor
DIGIT 10 - Electric Heater
0 = No Electric Heater
A = 5 kw (1 phase)
B = 6 kw (3 phase)
D = 10 kw (1 phase)
E = 12 kw (3 phase)
F = 14 kw (1 phase)
G = 18 kw (1 and 3 phase)
J = 23 kw (3 phase)
K = 27 kw (3 phase)
N = 36 kw (3 phase)
P = 54 kw (3 phase)
DIGIT 11 - Minor Design
Sequence
A = First Sequence
DIGITS 12,13 - Service Sequence
Factory Assigned
DIGIT 14 - Fresh Air Selection
0= No Fresh Air
A = Manual Outside Air Damper
0-50%
B = Motorized Outside Air Damper 0-
50%
C = Economizer, Dry Bulb 0-100%
without Barometric Relief
D = Economizer, Dry Bulb 0-100%
withBarometric Relief
E = Economizer, Reference Enthalpy
0-100% without Barometric Relief
F = Economizer, Reference Enthalpy
0-100% with Barometric Relief
G = Economizer, Comparative
Enthalpy 0-100% without
Barometric Relief
H = Economizer, Comparative
Enthalpy 0-100% with Barometric
Relief
DIGIT 15 - Supply Fan/Drive Type/
Motor
0= Standard Drive
1 = Oversized Motor
2 = Optional Belt Drive Motor
DIGIT 16 - Hinged Service
Access/Filters
0 = Standard Panels/Standard Filters
A = Hinged Access Panels/Standard
Filters
B = Standard Panels with 2 inch
MERV 7 pleated filter
C = Hinged Access Panels with 2 inch
MERV 7 pleated filter
D = Standard Panels with 2 inch
MERV 13 pleated filter
E = Hinged Access Panels with 2 inch
MERV 13 pleated filter
DIGIT 17 - Condenser Coil
Protection
0 = Standard Coil
1 = Standard Coil with Hail Guard
2 = Epoxy Coated Condenser Coil
3 = Epoxy Coated Condenser Coil
with Hail Guard
4 = *CompleteCoat Condenser Coil
5 = *CompleteCoat Condenser Coil
and Hail Guard
DIGIT 18 - Through the Base
Provisions
0 = No Through the Base Provisions
A = Through the Base Electric
DIGIT 19 - Disconnect/Circuit
Breaker (3 phase only)
0 = Without Disconnect Switch/Circuit
Breaker
1 = Unit Mounted Non-Fused
Disconnect Switch
2 = Unit Mounted Circuit Breaker
DIGIT 20 - Convenience Outlet
0 = No Convenience Outlet
A = Unpowered Convenience Outlet
B = Powered Convenience Outlet
(3 phase only)
DIGIT 21 - Communications
Options
0 = No Communications Interface
1 = Trane Communications Interface
2 = LonTalk® Communications
Interface
DIGIT 22 - Refrigeration System
Option
0 = Standard Refrigeration System
DIGIT 23 - Refrigeration Controls
0 = No Refrigeration Control
1 = High Pressure Control
2= Frostat
3 = Crankcase Heater
4 = High Pressure Control and Frostat
5 = High Pressure Control and
Crankcase Heater
6 = Frostat and Crankcase Heater
7 = High Pressure Control, Frostat
and Crankcase Heater
DIGIT 24 - Smoke Detector
0= No Smoke Detector
A = Return Air Smoke Detector
B = Supply Air Smoke Detector
C = Supply and Return Air Smoke
Detectors
DIGIT 25 - Monitoring Controls
0 = No Monitoring Control
1 = Clogged Filter Switch
2 = Fan Failure Switch
3 = Discharge Air Sensing Tube
4 = Clogged Filter Switch and Fan Fail
Switch
5 = Clogged Filter Switch and
Discharge
Air Sensing Tube
6 = Fan Fail Switch and Discharge Air
Sensing Tube
7 = Clogged Filter and Fan Fail
Switches and Discharge Air
Sensing Tube
WSC036A3RBA** C000A10001A1
123456789101112,13141516171819202122232425
