Trane XB 13 User Manual

 4 22-1769-07
Product Specifications
Model No. 1 2TTB3018A1000C 2TTB3024A1000C 2TTB3030A1000C 2TTB3036A1000C
Electrical Data V/Ph/Hz 2 200/230/1/60 200/230/1/60 200/230/1/60 208/230/1/60
Min Cir Ampacity 8 12 13 21
Max Fuse Size (Amps) 15 20 20 35
Compressor RECIP RECIP RECIP SCROLL
RL Amps - LR Amps 5.8 - 38.6 8.7 - 57.8 9.5 - 63 15.4 - 87
Outdoor Fan FL Amps 0.6 0.9 0.7 1.3
Fan HP 1/15 1/8 1/8 1/6
Fan Dia (inches) 19.0 19.0 23.0 23.0
Coil Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-22 (Not factory supplied) 4/00-LB/OZ 5/02-LB/OZ 5/08-LB/OZ 6/05-LB/OZ
Line Size - (in.) O.D. Gas 3 5/8 3/4 3/4 7/8
Line Size - (in.) O.D. Liquid 3 1/4 5/16 5/16 3/8
Dimensions H x W x D (Crated) 30.1 x 26.7 x 30 37.2 x 26.7 x 30 38 x 30.1 x 33 38 x 30.1 x 33
Weight - Shipping 182 195 225 205
Weight - Net 163 175 197 178
Start Components YES YES YES NO
Sound Enclosure NO NO NO NO
Compressor Sump Heat NO NO NO NO
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control A/C AY28X079 AY28X079 AY28X079 AY28X079
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101
Crank Case Heater Kit BAYCCHT300 BAYCCHT300 BAYCCHT300 BAYCCHT301
Hard Start Kit Scroll BAYKSKT260
Extreme Condition Mounting Kit BAYECMT001 BAYECMT001 BAYECMT001 BAYECMT001
Refrigerant Lineset 5 TAYREFLN1* TAYREFLN2* TAYREFLN2* TAYREFLN3*
1 Certified in accordance with the Unitary Air-Conditioner equipment certification program which is based on AHRI Standard 210/240.
2 Calculated in accordance with N.E.C. Use only HACR circuit breakes or fuses.
3 Standard line lengths - 60'. Standard lift - 60' Suction and Liquid line.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0
†
. (
†
denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
General
Data
A-weighted Sound Power Level [dB(A)]
MODEL SOUND POWER
LEVEL [Db(a)]
A-WEIGHTED FULL OCTAVE SOUND POWER LEVEL dB - [dB(A)]
63 125 250 500 1000 2000 4000 8000
2TTB3018A1 76 43.8 52.8 56.7 65.3 67.4 69.6 64.6 57.2
2TTB3024A1 78 50.9 55.9 63.2 71.2 72.0 70.5 64.3 56.8
2TTB3030A1 78 45.8 56.9 61.7 68.5 71.4 70.3 61.2 54.2
2TTB3036A1 76 44.8 60.5 61.4 69.2 72.1 65.2 57.3 51.3
2TTB3042A1 79 46.0 60.6 70.4 72.9 72.4 69.5 60.9 51.2
2TTB3048A1 79 49.3 57.7 71.0 72.2 72.7 70.5 63.7 53.7
2TTB3060A1 79 53.6 57.5 63.6 73.3 73.1 71.3 63.1 55.9
Note:TestedinaccordancewithAHRIStandard270.95.(NotlistedwithARI)

Trane XB 13 Specifications

General

Brand	Trane
Model	XB 13
Category	Air Conditioner
Language	English
