Trane YHC092E - Temperature Limit Switch Usage for Gas Heat Units

Installation
RT-SVX21K-EN 25
Temperature Limit Switch Usage for Gas
Heat Units
Units are factory shipped in the down flow discharge
configuration but can be field converted to a horizontal
discharge configuration. Some, but not all units require a
different TCO1 limit switch, which is attached to the
combustion blower motor if horizontal discharge
configuration is used.
Note: The following units require a limit switch change
out for horizontal discharge. The additional limit
switch is shipped attached to the combustion
blower housing: YSC036E**(M,Y),
YSC036E**(H,Z), YSC048E**(H,Z),
YSC048E**(M,Y) belt drive ID motor,
YSC060E**(H,Z) direct drive ID motor,
YHC047E**(L,X), YHC048E/F**(L,X) direct drive ID
motor, YHC060E/F**(L,X) belt drive ID,
YHC036E**(M,Y), YHC037E**(M,Y), YHC048E/
F**(M,Y), YHC060E/F**(M,Y) direct drive ID motor,
YHC036E**(H,Z), YHC048E/F**(H,Z) belt drive ID
motor, YHC060E/F**(H,Z), YSC072F**(H,Z),
YSC090F**(L,X), YSC092F**(M,Y),
YSC092E**(H,Z), YSC102F**(H,Z),
YSC120F**(M,Y), YSC120F**(H,Z),
YHC092E**(M,Y),YHC092F**(M,Y),
YHC102E**(M,Y), YHC120E**(L,X),
YHC120E**(H,Z).
If any of the aforementioned units are installed in the down
flow discharge configuration, remove the additional TCO1
limit switch from the combustion blower motor and
discard.
BD= Belt drive ID motor
DD= Direct drive ID motor
Table 3. TC01 tripping values
Unit Model
(Standard
Efficiency)
TCO1 Tripping
Values
Down flow/
Horizontal
Unit Model
(High Efficiency - 15
SEER)
TCO1 Tripping
Values
Down flow/
Horizontal
Unit Model
(High Efficiency -
17 Plus)
TCO1 Tripping
Values
Down flow/
Horizontal
YSC036E**(L,X)-DD 180F YHC036E**(L,X)-DD 180F YHC037**(L,X) 190F
YSC036E**(L,X)-BD 170F YHC036E**(L,X)-BD 170F YHC037**(M,Y) 170F / 220F
YSC036E**(M,Y)-DD 170F / 190F YHC036E**(M,Y)-DD 170F / 190F YHC037**(H,Z) 220F
YSC036E**(M,Y)-BD 180F / 190F YHC036E**(M,Y)-BD 180F / 190F YHC047**(L,X) 145F / 155F
YSC036E**(H,Z)-DD 170F / 190F YHC036E**(H,Z)-DD 170F / 190F YHC047**(M,Y) 170F
YSC036E**(H,Z)-BD 155F / 190F YHC036E**(H,Z)-BD 155F / 190F YHC047**(H,Z) 220F
YSC048E**(L,X)-DD 180F YHC048E/F**(L,X)-DD 145F / 155F YHC067**(L,X) 140F
YSC048E**(L,X)-BD 170F YHC048E/F**(L,X)-BD 155F YHC067**(M,Y) 170F
YSC048E**(H,Z)-DD 155F / 210F YHC048E/F**(M,Y)-DD 150F / 170F YHC067**(H,Z) 170F
YSC048E**(M,Y)-BD 170F / 190F YHC048E/F**(M,Y)-BD 170F / 180F
YSC048E**(M,Y)-DD 180F YHC048E/F**(H,Z)-DD 220F
YSC048E**(H,Z)-BD 155F / 200F YHC048E/F**(H,Z)-BD 220F / 260F
YSC060E**(L, X) 170 YHC060E/F**(L,X)-DD 140F
YSC060E**(M,Y) 170F YHC060E/F**(L,X)-BD 155F / 145F
YSC060E**(H,Z)-DD 170F / 200F YHC060E/F**(M,Y)-DD 145F / 170F
YSC060E**(H,Z)-BD 170F YHC060E/F**(M,Y)-BD 170F
YSC072F**(M,Y) 155F YHC060E/F**(H,Z)-DD 190F / 220F
YSC072F**(L,X) 170F YHC060E/F**(H,Z)-BD 220F / 230F
YSC072F**(H,Z) 145F / 155F YHC072F**(L,X) 200F
YSC090F**(L,X) 180F / 200F YHC072F**(M,Y) 190F
YSC090F**(M,Y) 155F YHC072F**(H,Z) 210F
YSC090F**(H,Z) 155F YHC092E**(L,X) 135F
YSC092F**(L,X) 225F YHC092E**(M,Y) 135F
YSC092F**(M,Y) 230F YHC092E**(H,Z) 170F
YSC092F**(H,Z) 220F /260F YHC092F**(L,X) 190F
continued on next page
