Unit Wiring Diagrams Numbers
62 RT-SVX21K-EN
Schematic Type Drawing Number Description
Connection ReliaTel
230V
4366-7340 YHC(037) (230V)
4366-7342 YHC(047-067) (230V)
4366-4564 Y(S,H)C(036,048)E/F (1-Phase), ReliaTel Controls
4366-5185
YHC(036,048)E/F (230V 3-Phase), ReliaTel Controls,
X13 IDM
4366-1522
Y(S,H)C(036-060)E/F (230V 3-Phase), ReliaTel
Controls, Belt-Drive IDM
4366-4705 Y(S,H)C060E/F (1-Phase), ReliaTel Controls
4366-5186 YHC060E/F (230V 3-Phase), ReliaTel Controls, X13 IDM
4366-1539 Y(S,H)C(072,090)F (230V), ReliaTel Controls
4366-7449 YHC(092-120)E (3-Phase), ReliaTel Controls
4366-1530 YSC(092,102)F (230V), ReliaTel Controls
4366-7451 (YSC120,YHC092)F (230V), ReliaTel Controls
460V and/or 575V
4366-7341 YHC(037) (460V)
Connection
ReliaTel 460V and/or 575V
4366-7343 YHC(047-067) (460V)
4366-5202 YHC(036,048)E/F (460V), ReliaTel Controls, X13 IDM
4366-1516
Y(S,H)C(036-060)F (460V,575V), ReliaTel Controls,
Belt-Drive IDM
4366-5203 YHC060E/F (460V), ReliaTel Controls, X13 IDM
4366-1540 Y(S,H)C(072,090)F (460V,575V), ReliaTel Controls
4366-1532 YSC(092,102)F (460V,575V), ReliaTel Controls
4366-7454 (YSC120,YHC092)F (460V), ReliaTel Controls
4366-7456 YSC120F (575V), ReliaTel Controls
Electromechanical
230V
4366-4562
Y(S,H)C(036,048)E (1-Phase), Electromechanical
Controls
4366-5183
YHC(036,048)E/F (230V 3-Phase), Electromechanical
Controls, X13 IDM
4366-1521
Y(S,H)C(036-060)E/F (230V 3-Phase),
Electromechanical Controls, Belt-Drive IDM
4366-4704 Y(S,H)C060E/F (1-Phase), Electromechanical Controls
4366-5184
YHC060E/F (230V 3-Phase), Electromechanical
Controls, X13 IDM
4366-1537 Y(S,H)C(072,090)F (230V), Electromechanical Controls
4366-6841 YHC(092-120)E (3-Phase), Electromechanical Controls
4366-1529 YSC(092,102)F (230V), Electromechanical Controls
4366-6866 (YSC120,YHC092)F (230V), Electromechanical Controls
460V and/or 575V
4366-5200
YHC(036,048)E/F (460V), Electromechanical Controls,
X13 IDM
4366-1523
Y(S,H)C(036-060)E/F (460V,575V), Electromechanical
Controls, Belt-Drive IDM
4366-5201
YHC060E/F (460V), Electromechanical Controls, X13
IDM
4366-1538
Y(S,H)C(072,090)F (460V,575V), Electromechanical
Controls
4366-1531
YSC(092,102)F (460V,575V), Electromechanical
Controls
4366-6867 (YSC120,YHC092)F (460V), Electromechanical Controls
4366-6868 YSC120F (575V), Electromechanical Controls
Table 17. Unit wiring diagram numbers (continued)
