Transcell Technology TI-500 User Manual

# of External Full Scale Input Range (mV/V)
Grads 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
500 75 50 25 25 25 25 25 25 25 25 25 25 25 25 25
1,000 150 75 50 50 25 25 25 25 25 25 25 25 25 25 25
1,500 200 100 75 50 50 50 25 25 25 25 25 25 25 25 25
2,000
–
150 75 75 50 50 50 50 25 25 25 25 25 25 25
2,500
–
200 100 75 75 50 50 50 50 50 50 25 25 25 25
3,000
–
200 150 100 75 75 50 50 50 50 50 50 50 25 25
4,000
– –
150 150 100 75 75 75 50 50 50 50 50 50 50
5,000 – – 200 150 150 100 100 75 75 75 75 50 50 50 50
6,000 –
– –
200 150 150 100 100 75 75 75 75 75 50 50
8,000 –
– – –
200 150 150 150 100 100 100 75 75 75 75
10,000 – –
– – –
200 200 150 150 150 150 100 100 100 75
12,000 – –
– – – –
200 200 150 150 150 150 150 100 100
15,000 – – –
– – – – –
200 200 200 150 150 150 150
20,000 – – – –
– – – – – – –
200 200 200 150
30,000 – – – – – –
– – – – – – – – –
40,000 – – – – – – – – –
–
– –
– –
–
Table C-1: Minimum Recommended (6:1) Span Gain Table
Page C-2
