3. To toggle between positive and negative peak weights, use the NET/GROSS key.
4. To reset both peak values to zero, press the ZERO key.
5. To exit peak hold mode, press the UNITS key again; the “P” annunciator turns OFF.
Accumulation (Totaling)
This mode of operation is enabled by setting F30 to “1” in the Setup Menu (see separate in-
staller’s guide for more information). The mode allows you to add weighments together to obtain
a total weight. When a tare weight is active, the net weight is added automatically.
1. Load the system with the weight that is to be added.
2. Press the PRINT key to add the current load to the weight accumulator.
3. The display briefly shows the message “ADDED” and then automatically returns to the
weighing mode.
4. If a printer is installed, a printout will be made. The gross, net and tare weights are to-
taled.
5. No weight can be recorded twice. The system needs to be returned to the net zero-
range before another weight can be added.
6. The subtotal can be checked by pressing the PRINT key two times while at net zero.
The display toggles between the net total weight and the number of weighments for 3-5
seconds.
• If the PRINT key is pressed during this period, then the total is printed (if option is in-
stalled) and reset to zero.
• If the NET/GROSS key is pressed during this period, then the total is reset to zero but
not printed.
• If no key is pressed during this period, then the subtotal stays in memory and the sys-
tem returns to the weighing mode.
Printer
If the weighing system has been equipped with a printer, then weighing and time & date data
can be printed.
Here is an example of a possible printout:
ID.NO. 123456
DATE 01/28/11
TIME 10:23 AM
GROSS 1067 lb
TARE 67 lb
NET 1000 lb
PCS 1000
NOTES:
1. Some fields may not appear on your printout, depending upon your configuration
settings
2. The TARE and NET fields are printed only when a tare has been established in the
system.
