Fiber Cable
BitErrorRate:<10‐9
Singlemodefiber(recommended): 9μm
Multimodefiber(recommended): 62.5/125μm
Multimodefiber(optional):  100/140,85/140,50/125μm
E‐100BTX‐FX‐06   1300nmmultimode
FiberOpticTr ansmitterPower: min:‐19.0dBm max:‐14.0dBm
FiberOpticReceiverSensitivity: min:‐30.0dBm max:‐14.0dBm
LinkBudget:11.0dbm

E‐100BTX‐FX‐06(SC)&(LC)  1300nmmultimode
FiberOpticTr ansmitterPower: min:‐19.0dBm max:‐14.0dBm
Fiber
OpticReceiverSensitivity: min:‐30.0dBm max:‐14.0dBm
LinkBudget:11.0dbm

E‐100BTX‐FX‐06(SM)   1310nmsinglemode
Fiber‐opticTransmitterPower:  min:‐15.0dBm max:‐8.0dBm
Fiber‐opticReceiverSensitivity: min:‐31.0dBm max:‐8.0dBm
LinkBudget:16.0dbm

E‐100BTX‐FX‐06(SMLC)  1310
nmsinglemode
Fiber‐opticTransmitterPower:  min:‐15.2dBm max:‐8.0dBm
Fiber‐opticReceiverSensitivity: min:‐32.5dBm max:‐3.0dBm
LinkBudget:17.3dbm

Thefiberoptictransmittersonthisdevicemeet ClassILasersafetyrequirementsperIEC‐825/CDRHstandards
andcomplywith21CFR1040.10 and2 1CFR1040.11.

