Transpak TP-201CE - Page 10

-8-
c. TP-202L / TP-202LCE
d. TP-203 / TP-203CE
e. TP-201Y / TP-201YS
MODEL TP-202L / TP-202LCE
Sealing method Heat
Net Weight 80kg (176 lbs)
Max. Tension 45kg (99 lbs)
Strap Width 6mm to 15.5mm (1/4" to 5/8")
Noise emission 78 dB (A)
Ambient temp
5 C

~ 40 C

(41 F

~ 104 F

)
MODEL TP-203 / TP-203CE
Sealing method Heat
Net Weight 80kg (176 lbs)
Max. Tension 9kg ~ 30kg (19.8 lbs ~ 66.1 lbs)
Strap Width 6mm to 15.5mm (1/4" to 5/8")
Noise emission 78 dB (A)
Ambient temp
5 C

~ 40 C

(41 F

~ 104 F

)
MODEL TP-201Y / TP-201YS
Sealing method Heat
Net Weight 125kg (275 lbs)
Max. Tension 45kg (99 lbs)
Strap Width 6mm to 15.5mm (1/4" to 5/8")
Noise emission 78 dB (A)
Ambient temp
5 C

~ 40 C

(41 F

~ 104 F

)
