Transpak TP-202 - Electrical and Technical Specifications

-7-
(3) Electrical Specifications
System configuration：
1L+N+PE (Ground) 1L+N+PE (Ground)
Nominal power：
0.5 KW 0.5 KW
Rated current：
7A 10A
Rated voltage：
220V/230V/240V 110V
Rated frequency：
50Hz 60Hz
Type of current：
AC - single phase AC - single phase
Minimum Requirements
The electrical supply line for the machine must have a minimum cross-section of at least
3C × 1.0mm
2
.
(4) Technical Data
a. TP-201 / TP-201CE
b. TP-202 / TP-202CE
MODEL TP-201 / TP-201CE
Sealing method Heat
Net Weight 100kg (220 lbs)
Max. Tension 45kg (99 lbs)
Strap Width 6mm to 15.5mm (1/4" to 5/8")
Noise emission 78 dB (A)
Ambient temp
5 C

~ 40 C

(41 F

~ 104 F

)
MODEL TP-202 / TP-202CE
Sealing method Heat
Net Weight 85kg (187 lbs)
Max. Tension 45kg (99 lbs)
Strap Width 6mm to 15.5mm (1/4" to 5/8")
Noise emission 78 dB (A)
Ambient temp
5 C

~ 40 C

(41 F

~ 104 F

)
