REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
41 TE-041 Body Frame 1
TE-041S Body Frame (Stainless Steel Model) 1
TK-033 Body Frame (Only CE) 1
TK-033S Body Frame (Stainless Steel Model)
(Only CE)
1
42 TE-042 Magnet Catch 4
43 TE-043 Side Door (L) 1
TE-043S Side Door (L)(Stainless Steel Model) 1
44 TE-044 Side Door (R) 1
TE-044S Side Door (R)(Stainless Steel Model) 1
45 TE-045 Support 1
TE-045S Support (Stainless Steel Model) 1
46 TC-043 Top Plate 1
TC-043S Top Plate (Stainless Steel Model) 1
47 TE-001A Reel Unit 1
48 TE-021A Brake Arm Ass'y 1
49 TE-030A Band Guide Bracket Ass'y 1
51 HB0612 HB, M6×12 20
53 TMS0305 TMS, M3×5 8
55 HBS0620 HBS, M6×20 7
56 HB0620 HB, M6×20 2
57 SW06 SW, M6 27
58 SR10 Stop Ring, S-10 3
59 PW06C PW, M6 (C) 30
60 PW06A PW, M6 (A) 2
61 PW06B PW, M6 (B) 2
63 WN06 WN, M6 2
64 HN06 HN, M6 11
67 TMS0612 TMS, M6×12 1
68 TC-068 Collar 1
69 NTE06 NTE, M6 2
70 TC-070 Shaft 2
-15-
