Transpak TP-202CE - Page 39

REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
71 FMS0612 FMS, M6×12 1
73 T5-2-10170 Hinge 1
75 TC-075 Center Drum 280mm 1
76 TC-076 Washer 1
77 ER19 Snap Ring, E-19 1
78 TB-205 Guide 1
84 HBS0612 HBS, M6×12 2
85 TMS0408 TMS, M4×8 2
86 SW04 SW, M4 2
87 HN04 HN, M4 2
89 PW05 PW, M5 4
90 SW05 SW, M5 4
91 HN05 HN, M5 4
94 HB0610 HB, M6×10 1
95 PMS0408 PMS, M4×8 2
96 LA-31010 Label 1
-16-
